current location:Home>Products>Manual Positioners>Translation Stages

PTS300 series precision postitioning stages

    1.Actuated with V-shapedguide and linear roller.

    2.Driven with micrometer head. Micrometer locations can be either side or middle of the stage.

    3.High precision and large bearing capacity

    4.The motion can be easily locked withthe knobon the side of the stage.

    6.Standard threaded holes on both top and bottom of the stages allow secure mounting to optical tables, or additional stages for multi-axes translation.

  • description
  • parameters

PTS300 series precision postitioning stages



1.Actuated with V-shapedguide and linear roller.

2.Driven with micrometer head. Micrometer locations can be either side or middle of the stage.

3.High precision and large bearing capacity

4.The motion can be easily locked withthe knobon the side of the stage.

6.Standard threaded holes on both top and bottom of the stages allow secure mounting to optical tables, or additional stages for multi-axes translation.


Related Products

     COMBINATED STAGES





Model

PTS301M

PTS302M

PTS303M

PTS304M

PTS305M

PTS306M

PTS307M

PTS308M

Table size mm

37×37

65×65

90×90

Travel mm

6

13

25

Driving

Micrometer head

Precisionmm

0.003

Resolutionmm

0.002

Graduationmm

0.01

Drive position

middle

side

middle

side

middle

side

middle

side

Loading capacity(kg)

5

12

15

Weight kg

0.5

0.5

0.7

0.7

0.7

0.7

0.9

0.9
