current location:Home>Products>Motion Control>Vertical Stages

MVS200 series motorized vertical translation stages

    1. The transmission adopts worm and worm gear structures with linear bearing guide rail.

    2.High precision, large bearing capacity

    3.Zero position photoelectric switch is included. Travel limit switches are located at both ends of the stage for accurate positioning and protection.

  • description
  • parameters

MVS200 series motorized vertical translation stages



1. The transmission adopts worm and worm gear structures with linear bearing guide rail.

2.High precision, large bearing capacity

3.Zero position photoelectric switch is included. Travel limit switches are located at both ends of the stage for accurate positioning and protection.



Related Products

STEPPER MOTOR CONTROLLERS          MOTORIZED POSITIONING UNITS



Model

MVS202

MVS204

MVS205

Travelmm

100

200

200

Table size (mm

Φ200

400×400

Φ500

Gear ratio

451

601

601

Screw pitch

3

6

6

Resolutionmm

0.001

0.001

0.001

Resetting positioning accuracy (mm

0.005

0.005

0.005

Maximum speed (mm/s)

0.20

0.50

0.50

Stepper motor1.8°)

56 stepper motor

86 stepper motor

Loading capacity(kg)

40

80

200

Weightkg

15

80

120
